BLOCK Transformer, 6VA, Encapsulated Safety Isolating - 24V

The BLOCK Transformer, 6VA is a high-quality encapsulated safety isolating transformer designed to provide safe electrical isolation between the input and output sides. It is specifically engineered for creating SELV (Safety Extra-Low Voltage) and PELV (Protective Extra-Low Voltage) circuits, thanks to its limited output voltage, making it an ideal choice for applications where electrical safety is critical.

This transformer features a dual primary and dual secondary winding configuration, offering flexible voltage setup options for both series and parallel connections. It operates across a frequency range of 50Hz to 60Hz, ensuring compatibility with standard mains supplies. With a slim, low-height profile, it is perfect for space-constrained applications where minimal size at high output is required.

Key Benefits

• XtraDenseFill Resin Encapsulation: Provides permanent corrosion protection, high insulation value, and maximum electrical reliability.
• Self-Extinguishing Potting Material: Enhances safety by preventing the spread of flames.
• Through-Hole Mounting: Facilitates easy and secure PCB installation.

Typical Applications

This PCB transformer is suitable for a wide range of industrial applications requiring reliable, isolated power. Its robust construction and encapsulated design make it a dependable component for various electronic devices and control systems.

The BLOCK FL Series transformer is a testament to quality engineering, delivering consistent performance and safety in a compact and durable package.

Variant Details

• Size: 24V
