Moore & Wright Protractor Depth Gauge, Metric/Imperial, 0-6in
Precise Moore & Wright protractor depth gauge (0-6in) with metric/imperial scales for accurate measurements in workshops.
The Moore & Wright Protractor Type Depth Gauge offers precise measurements with its full range rule adjustment, ideal for engineers and craftsmen. Equipped with a locknut to secure readings, it ensures accuracy in various applications. Rules are graduated on both sides, providing flexibility in measurement systems.
The protractor plate is finely graduated from 0° to 180° and back to 0°, with a scale resolution of 0.5°, allowing for detailed angular measurements. This tool is essential for tasks that require high precision in both depth and angle assessments.
A sturdy base size of 79mm (3.11in), coupled with a blade width of 5.5mm (0.22in) and thickness of 1.0mm (0.04in), ensures durability and ease of use. The blade extends to 195mm (7.68in), accommodating a wide range of measurement needs.
Additional Features
- Metric/Imperial Scale Graduations: Front face offers 1/32nd inch graduations, while the rear face provides 1.0mm graduations for versatility.
- High-Quality Construction: Built to withstand rigorous use in workshops and on-site applications.
With the Moore & Wright Protractor Depth Gauge, you gain a reliable and precise tool for all your measuring needs.
- Engineering workshops
- Metalworking
- Woodworking
- Precision measurement tasks
- Base Size: 79mm / 3.11in
- Blade Width: 5.5mm / 0.22in
- Blade Thickness: 1.0mm / 0.04in
- Blade Length: 195mm / 7.68in
- Scale Resolution: 0.5°
- Metric/Imperial Graduations: Front - 1/32nd inch, Rear - 1.0mm
