Multicomp Pro 25-Pin Unthreaded IDC D-Sub Plug, Gold/Nickel
Durable 25-pin unthreaded D-sub plug by Multicomp Pro with gold/nickel-plated brass contacts for industrial and networking applications.
The Multicomp Pro 25-Pin Unthreaded IDC D-Sub Plug (8FSM25P-30N1-FEC) is a high-performance connector designed for industrial and networking applications. This male D-subminiature plug features gold over nickel-plated brass contacts for excellent conductivity and corrosion resistance. The metal shell provides durability and stability, while the PBT + glass-fibre reinforced insulator ensures reliable insulation and mechanical strength.
Ideal for 28 AWG and 26 AWG stranded wire gauge, this connector accepts 1.27 mm conductor centre flat cable, offering a secure connection with IDC (Insulation Displacement Contact) termination. Its standard through-hole plastic housing enhances ease of installation for cable-mounted applications.
Performance Specifications
- Maximum Contact Resistance: 15 mΩ
- Minimum Insulation Resistance: 1000 MΩ
- Dielectric Withstanding Voltage: 500 VAC for 1 minute
- Operating Temperature Range: -55°C to 105°C
Please note: Market demand may lead to extended lead times, and this product is exempt from discounts.
- Industrial applications
- Communications equipment
- Networking systems
- D Sub Connector Type: Standard
- Gender: Plug
- No. of Contacts: 25
- D Sub Shell Size: DB
- Contact Termination Type: IDC / IDT
- Connector Mounting: Cable Mount
- Contact Material: Brass
- Contact Plating: Gold over Nickel Plated
- Connector Body Material: Metal Body
- Housing Material: PBT + Glass-Fibre Reinforced
- Compatible Wire Gauge: 28 & 26 AWG
- Cable Type: 1.27 mm Centre Flat Cable
- Weight: 10 g
