Multicomp Pro 2.54mm Crimp Housing, 12-Way, Single Row
12-way, 2.54mm pitch crimp housing for industrial and networking applications with high-temperature plastic insulator. UL 94V-0 rated.
The Multicomp Pro 2.54mm Crimp Housing offers a reliable and versatile solution for electrical connections with a 2.54mm pitch spacing. Designed for single-row applications, this 12-way receptacle housing provides secure connectivity for various industrial and communication needs. The housing features a high-temperature plastic insulator with a flammability rating of UL 94V-0, ensuring safety and durability in demanding environments.
This housing is compatible with the 2211S header series, making it ideal for seamless integration in your projects. The black colour housing ensures a professional finish, while the miniature latch provides secure mating and stable connections.
Key Features
- 3A AC/DC rated current
- 250VAC/DC rated voltage
- 20mΩ maximum contact resistance
- 1000MΩ minimum insulation resistance
- 600VAC for one minute withstanding voltage
- Operating temperature range: -40 to +105°C
Applications
- Communications & Networking
- Industrial equipment
Please note that due to high market demand, lead times for this product may vary. Additionally, this product is exempt from discounts.
- Communications & Networking
- Industrial applications
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Pitch Spacing: 2.54mm
- No. of Positions: 12 Ways
- Gender: Receptacle
- Mate Compatibility: 2211S header series (2226A)
- Rated Current: 3A AC/DC
- Rated Voltage: 250VAC/DC
- Maximum Contact Resistance: 20mΩ
- Minimum Insulation Resistance: 1000MΩ
- Withstanding Voltage: 600VAC for one minute
- Operating Temperature Range: -40 to +105°C
- Material: High-temperature plastic
- Colour: Black
- Flammability Rating: UL 94V-0
- Weight: 900g
