PRO ELEC 25A Single Pole RCBO, C Curve, 30mA

The PRO ELEC 25A Single Pole RCBO is a high-quality residual current circuit breaker with overcurrent protection, designed to provide reliable safety for electrical circuits. This RCBO combines the functions of a circuit breaker and residual current device (RCD) in a compact, single-pole unit, offering efficient protection against overloads, short circuits, and earth leakage faults.

With a breaking capacity of 6kA, it can handle significant fault currents while maintaining safety. The RCBO is suitable for cables up to 25mm², making it versatile for various electrical installations. Its slim design, at just 17.6mm per module, ensures easy integration into tight consumer unit spaces without compromising performance.

This RCBO complies with IEC61009 and EN61009 standards, ensuring quality and safety for residential and commercial applications. Its voltage rating of 230V AC and current rating of 25A make it ideal for protecting dedicated circuits, such as lighting and socket outlets.

Key Specifications

• Breaking Capacity: 6kA
• Cable Compatibility: Up to 25mm²
• Width per Module: 17.6mm
• Voltage Rating: 230V AC
• Current Rating: 25A
• Poles: Single Pole (1P)
• Trip Curve: C Curve (medium inrush current handling)
• Sensitivity: 30mA (providing excellent protection against earth faults)

This PRO ELEC RCBO is a dependable choice for enhancing electrical safety, preventing potential hazards such as electric shocks and circuit overheating.
