SENSATA/CRYDOM CX Series Solid State Relay - 50A 240V
- SKU
- C3-SW03823
- EAN
- 3562124162783
High-density 5A SSR for PCB mounting. Zero-crossing or instantaneous turn-on. UL, CSA, VDE approved for industrial automation and power control.
This item is currently out of stock...
This item is currently out of stock, but you may opt in to be notified when it is back in stock.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Free UK deliveryOrder by 13:58 UK time on a working day for same-day dispatch
- 30-day returnsUnused, in original packaging
- Secure checkoutCard, PayPal, Apple Pay, Google Pay
Technical Specifications
- Industrial automation systems
- Heating control applications
- Lighting control systems
- Motor control circuits
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Series: 1 Series
- Base Plate Material: Aluminium
- Housing Rating: 94V-0
- Contact Configuration: SPST-NO
- Switching Mode: Zero Crossing
- Terminals: Screw
- Mounting Type: Panel Mount
- Output Type: SCR for heavy industrial loads
- Maximum On-State Voltage Drop: 1.15Vrms
- Dielectric Strength: 4000Vrms
- Control: AC or DC
- Nominal Input Impedance: Current regulated
- Maximum Turn-On/Off Time: 1/2 cycle ms
- Ambient Operating Temperature Range: -40°C to 80°C
- Design Feature: Epoxy-free
- Compliance: EMC compliant to level-3
- Key Feature: Direct bond copper substrate
- Key Feature: Direct power lead frame
- Key Feature: Improved SEMS screw and washer
- Key Feature: Redesigned housing with anti-rotation barriers
- Dimensions (H x W x D): 43mm x 33mm x 15mm
- Weight: 110 grams
- Load Current: 50A
- Operating Voltage Max: 280VAC
- Relay Mounting: Panel Mount
- Relay Terminals: Screw
- Operating Voltage Min: 24VAC
- Control Voltage Min: 3VDC
- Control Voltage Max: 32VDC
- Product Range: 1 Series
- SVHC: No SVHC (07-Jul-2017)
