Timco M12 x 100mm Zinc Plated Throughbolts (Pack of 12)
Zinc-plated throughbolts (M12 x 100mm) for concrete anchoring. Grade 5.8 carbon steel & corrosion-resistant finish.
The Timco M12 x 100mm Zinc Plated Throughbolts provide a secure and efficient solution for anchoring into concrete and other robust substrates. These versatile fixings are torque-controlled for precise installation, ensuring a firm and long-lasting hold in various structural applications.
Each throughbolt features a chamfered head design, protecting the threads from damage during installation. The zinc plating (3-5 microns) with passivation ensures superior corrosion resistance, making these fasteners ideal for both indoor and outdoor use. Additionally, the special expansion clip enables rapid and straightforward installation, saving time and effort on-site.
Made from cold-formed carbon steel (grade 5.8), these throughbolts combine high tensile strength with excellent durability. They are designed to accommodate a variety of fixture thicknesses, making them suitable for a wide range of construction and DIY projects.
Key Specifications:
- Thread Diameter: M12
- Length: 100mm
- Nut Socket Size: 19mm
- Material: Carbon Steel (Grade 5.8)
- Finish: Zinc Plated & Passivated
- Drill Hole Diameter: 12.0mm
- Fixture Hole Diameter: 14.0mm
- Edge Distance: 75mm
- Max Fixture Thickness: 25mm
- Min Drill Hole Depth: 60mm
Installation Note: If no torque wrench is available, tightening the nut 3 to 4 full turns after finger-tight will ensure a secure fit.
- Concrete anchoring
- Structural fixings
- Heavy-duty construction
- Outdoor applications
- Thread Diameter: M12
- Length: 100mm
- Nut Socket Size: 19mm
- Material: Carbon Steel (Grade 5.8)
- Finish: Zinc Plated & Passivated
- Drill Hole Diameter: 12.0mm
- Fixture Hole Diameter: 14.0mm
- Edge Distance: 75mm
- Max Fixture Thickness: 25mm
- Min Drill Hole Depth: 60mm
