Timco M16 x 105mm Zinc Throughbolts (25 Pack)
High-strength M16 x 105mm zinc-plated throughbolts for secure concrete anchoring. Torque-controlled fastening with nuts & washers.
The Timco M16 x 105mm Zinc Throughbolts (25 Pack) provides a torque-controlled, highly durable fixing solution for concrete anchoring applications. These bolts come complete with a hex full nut and washer, ensuring a strong and secure fastening every time.
Designed for efficiency, these throughbolts feature a chamfered head, protecting the threads during installation. Zinc-plated and passivated (3–5 microns), they offer excellent corrosion resistance. Made from cold-formed carbon steel (Grade 5.8), they deliver high tensile strength and long-lasting performance.
Key Benefits:
- Easy installation—Special expansion clip for rapid fixing.
- Versatile use—Suitable for a wide range of anchoring applications.
- Corrosion-resistant—Zinc-plated for enhanced durability.
- Secure tightening—No torque wrench? Just tighten 3–4 full turns from finger tight.
Ideal for:
- Heavy-duty structural anchoring
- Concrete fixture installations
- High-load fastening applications
- Concrete anchoring
- Heavy-load structural fixings
- Construction applications
- Industrial installations
- Thread Diameter: M16
- Length: 105mm
- Nut Socket Size: 24mm
- Material: Carbon Steel (Grade 5.8)
- Finish: Zinc Plated (3–5 microns)
- Drill Hole Diameter: 16.0mm
- Fixture Hole Diameter: 18.0mm
- Edge Distance: 100mm
- Max Fixture Thickness: 5mm
- Min Drill Hole Depth: 75mm
- Pack Quantity: 25
Always follow local regulations and product guidance.
