VIGORTRONIX 3VA PCB-Mount Isolation Transformer, Dual Primary & Secondary - 12V

The VIGORTRONIX 3VA PCB-Mount Isolation Transformer is a high-quality Euro-specification component engineered for reliable power management and industrial applications. This open-frame safety isolating transformer is designed for direct through-hole mounting onto printed circuit boards, providing robust electrical isolation and voltage conversion in a compact, efficient package.

Featuring a dual 115V AC primary winding and a dual 9V AC secondary winding, it offers flexible configuration options to suit various circuit design requirements. The transformer boasts a 3VA power rating, making it suitable for low-power control circuits, signal isolation, and auxiliary power supplies where safety and reliability are paramount.

Manufactured to exacting standards, this component is compliant with EN61558 and EN60950 safety regulations and carries the CE mark, ensuring it meets rigorous European safety and performance directives. It is constructed with a Class-B (130°C) temperature rating, allowing it to operate reliably in elevated temperature environments common in industrial settings. Furthermore, it features an impressive 3750Vrms dielectric strength, providing a high level of insulation and protection against electrical breakdown.

Its through-hole mounting design ensures a secure mechanical and electrical connection to the PCB. The compact dimensions make it an ideal choice for space-constrained applications without compromising on performance or safety specifications. This transformer is a fundamental component for designers and engineers seeking a dependable, certified solution for creating isolated power domains within electronic equipment.

Variant Details

• Size: 12V
