BLOCK PCB Mount Safety Isolation Transformer 230V 2.8VA - 15V
- SKU
- C3-TF01296
- EAN
- 3562134192329
BLOCK PCB mount safety isolation transformer, 230V input, dual 15V 2.8VA output. Encapsulated, short-circuit proof for SELV/PELV circuits.
This item is currently out of stock...
This item is currently out of stock, but you may opt in to be notified when it is back in stock.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Free UK deliveryOrder by 13:58 UK time on a working day for same-day dispatch
- 30-day returnsUnused, in original packaging
- Secure checkoutCard, PayPal, Apple Pay, Google Pay
Technical Specifications
- As a mains transformer for voltage adjustment
- For safe electrical isolation of input and output circuits
- Creating SELV (Safety Extra-Low Voltage) circuits
- Creating PELV (Protective Extra-Low Voltage) circuits
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Transformer Type: Encapsulated Safety Isolating
- Primary Voltage: 230V AC
- Secondary Voltage: 2 x 15V AC
- Rated Power: 2.8VA
- Frequency Range: 50Hz to 60Hz
- Efficiency: 57.0%
- Winding Type: Single Primary, Dual Secondary
- Current Rating: 93mA
- Mounting Type: Through Hole (PCB Mount)
- Terminal Type: Pins for printed circuit boards
- Pin Diameter: 0.8mm
- Protection Index: IP00
- Insulation Class: VDE Class B, UL Class 105
- Potting Material: Self-extinguishing resin encapsulation (XtraDenseFill)
- Operating Temperature Range: -20°C to +70°C
- Dimensions (W x H x D): 32.3mm x 34mm x 27.3mm
- Weight: 7 grams
- Product Range: VB Series
- Primary Voltages: 230V
- Secondary Voltages: 2 x 15V
- Power Rating: 2.8VA
- Transformer Mounting: Through Hole
- SVHC: No SVHC (21-Jan-2025)
