BLOCK PCB Mount Safety Isolation Transformer 230V 2.8VA - 9V

The BLOCK PCB Mount Safety Isolation Transformer is a compact, high-reliability mains transformer designed for voltage adjustment and secure electrical isolation. It functions as a safety isolating transformer, effectively and safely separating the input and output sides of a circuit. This makes it suitable for creating Safety Extra-Low Voltage (SELV) and Protective Extra-Low Voltage (PELV) circuits, where the limited output voltage enhances user safety.

Constructed with permanent corrosion protection and a high insulation value, this transformer delivers maximum electrical reliability. This is achieved through its XtraDenseFill resin encapsulation, which not only protects the internal components from environmental factors but also provides a self-extinguishing potting material for added safety. The transformer is designed to perform reliably in high ambient temperatures, making it suitable for a wide range of industrial and electronic applications.

Key Features & Specifications

• High Efficiency & Compact Design: Offers a rated power of 2.8VA with 57.0% efficiency, providing a high output from a minimum size. Its inherently short-circuit proof design ensures robust operation.
• Dual Output Voltage: Features dual 15VAC outputs that can be configured for series or parallel connection, offering excellent flexibility in circuit design.
• Broad Compatibility: Rated for an input voltage of 230VAC and a frequency range of 50 to 60Hz, making it suitable for standard UK and European mains supplies.
• Secure Mounting: Equipped with pins for printed circuit board (PCB) terminals, featuring 0.8mm diameter pins for secure through-hole mounting.
• Robust Encapsulation: The encapsulated type construction provides an IP00 protection index and meets VDE class B and UL class 105 insulation standards.
• Wide Operating Range: Can operate in an ambient temperature range from -20°C

Variant Details

• Size: 9V
