Grove EMG Detector Kit with Electrodes and Cables

The Grove EMG Detector serves as a bridge between the human body and electronic systems, enabling the detection and measurement of muscle activity. This sophisticated sensor captures small muscle signals, which are then processed through a two-stage amplification and filtering circuit to produce a clean, readable output signal compatible with Arduino and other microcontrollers.

In its standby state, the sensor maintains a stable output voltage of 1.5V. Upon detecting muscle activation, the output signal rises proportionally, reaching a maximum voltage of 3.3V. This variable output allows for precise monitoring of muscle contractions and activity levels. The detector is versatile in its power requirements, functioning seamlessly within both 3.3V and 5V systems, making it adaptable to a wide range of development boards and projects.

The kit is designed for ease of use and integration. It features the standard Grove 3.5mm 4-pin connector for quick and reliable connection to Grove system base shields. For interfacing with the human body, the package includes six disposable surface electrodes and a generous 1000mm cable lead set, providing ample length for comfortable placement and experimentation. No additional power supply is required beyond the main microcontroller board.

Key Specifications and Contents

• Output Signal: Variable voltage from 1.5V (standby) to 3.3V (max muscle activity).
• Compatibility: Works with 3.3V and 5V microcontroller systems, including Arduino.
• Interface: Grove-compatible 3.5mm 4-pin connector.
• Cabling: Supplied with 1000mm electrode cable leads and a Grove connection cable.
• Power Supply: Operates on 3.3V to 5V DC, drawn from the main board.

Package Contents

The kit includes everything needed to get started: one EMG Detector board, one Grove 4-pin cable, six disposable surface electrodes, and a DC jacket to push
