VIGORTRONIX PCB Mount Isolation Transformer, 12VA - 6V

The VIGORTRONIX 12VA PCB Mount Isolation Transformer is a high-quality Euro PCB-mount component designed for reliable power management and industrial applications. This robust transformer features dual 115VAC primary windings and dual 6VAC secondary windings, offering flexible configuration options for various circuit designs. With a power rating of 12VA and a frequency range of 50Hz/60Hz, it delivers consistent performance across a wide range of environments.

Engineered to stringent standards, this transformer is manufactured and tested in accordance with EN61558, EN60950, and CE requirements, ensuring safety and reliability. It boasts a 130°C Class-B temperature class and a 3750Vrms dielectric strength, providing excellent thermal and electrical insulation. The open frame safety isolating design, combined with through-hole mounting, makes it easy to integrate into PCB assemblies.

This transformer offers a 1A current rating and a 12% regulation, ensuring stable output under varying loads. Its compact dimensions (43mm height, 33mm width, 15mm depth) and lightweight construction (360g) make it an ideal choice for space-constrained applications. Whether used in power supplies, control systems, or industrial equipment, this isolation transformer delivers dependable performance and long service life.

Applications

• Power management systems
• Industrial control equipment
• General electronic circuit isolation

Key Features

• Dual primary and secondary windings for flexible configuration
• High dielectric strength and thermal rating
• Compliant with international safety standards
• Compact, PCB-mountable design

Variant Details

• Size: 6V
